Icom IC-F5122D / IC-F6122D

Entry Level IDAS Digital Mobile Series

The new IDAS IC-F5122D mobile series is a simple and straight forward range that offers business and industry radio users 6.25 kHz channel spacing, digital/analogue mixed mode operation in a mobile. Ideal for transportation, and delivery fleets, the streamlined IC-F5122D series has an abundance of mobile features and is compatible with IDAS multi-site conventional and IDAS single-site trunking thus providing an affordable digital migration path from analogue.

Entry Level IDAS Digital Mobile Radio capable of multi-site conventional and single-site trunking.

The IC-F5122D series provides basic operation in IDAS digital mode. It is also compatible with IDAS multi-site conventional and IDAS single-site trunking.

External GPS receiver connection with optional OPC-2078 ACC cable.

The new optional OPC-2078 is a D-SUB 25-pin ACC cable can connect with an external GPS receiver or PC connection. An optional OPC-1939 D-SUB 15-pin ACC cable is also available with the IC-F5122D series.

Max. 128 memory channels and 8 memory zones.

The IC-F5122D series has 128 memory channels (Max.) with 8 zones. Memory channel selection can be easily selected with the up/down buttons.

Alphanumeric LCD.

The IC-F5122D series has an easy to read an 8-character 14 segment alphanumeric LCD. The “ ” icon on the upper right of the display shows the scanning is activated.

4W (typical) front mounted loud speaker.

The IC-F5122D series has a 4W (typical) front mounted speaker which can be clearly heard during operation.

Multi 5-tone function built-in.

The IC-F5122D series has built-in 5-Tone, CTCSS and DTCS signalling capabilities for group communication. The IC-F5122D series can decode up to eight 5-tone codes on a channel. The following actions are programmable to respond to each tone.

• Beep sound
• Bell icon
• Answer back call
• Auto TX
• Stun, kill revive
• Scanning
• External output*

* External device connection such as a horn honk, buzzer, etc is required.

Talk back function and call mode selection.

When the talk back function is enabled, the IC-F5122D series automatically selects the received channel and talkgroup or individual ID (IDAS digital mode) to reply to the received call, while scanning stops or resumes after a preset time. The talk back timer beep alerts you of the end of the talk back time with a beep sound. The user can easily make a quick response with this function.

Other features
• BIIS PTT ID transmission
• 8 DTMF autodial memories
• ±1.0ppm frequency stability both in VHF and UHF
• Common programming software with IC-F3102D series
